PS42D02B Series DIP Type Push Switch 系列插件式按鈕開關

Specification:

產品規格:

• Rating額定電流: 0.3A 30V DC.
• Function功能: OFF-(ON).
• Contact resistance接觸電阻: 300mΩ Max.
• Insulation resistance絕緣電阻: 100MΩ Min. at 500V DC.
• Withstand voltage耐電壓: 500V AC for 1 minute.
• Operating force操作力: 250±100g.
• Operating life壽命次數: 10,000 Cycles.
