2018 New Products

2018.01.10 2018 New Products 瀏覽人數:2595

MW Series Anti-vandal High Current Switch  系列防破壞高電流開關






Specification:
產品規格:

  • Rating額定電流: 16A、21A、25A 125V/250V AC
  • Travel行程: 3.2mm
  • Contact resistance接觸電阻: 50mΩ Max. @1A 12V DC(initial)
  • Insulation resistance絕緣電阻: 100MΩ Min. at 500V DC
  • Withstand voltage耐電壓: 1500V RMS@sea level
  • Operating temperature操作溫度: 16A&21A: -40℃ ~ 105℃ / 25A: -40℃ ~ 85℃
  • Operating force操作力: 4 ~ 6N
  • Mechanical life機械壽命次數: 1000,000 Cycles
  • Electrical life電氣壽命次數: 16A: 50,000 Cycles / 21A: 50,000 Cycles / 25A: 20,000 Cycles
  • Waterproof level防水等級: IP67
